Garrett G42 1450 Supercore


Saadaval järeltellimisel

Garrett G42-1450 turbo for 2.0 – 8.0L engine displacement up to 1450 horsepower. Read our guide and get more power and durability by choosing the right G42 turbo.

Horsepower: 525 – 1450HP
Displacement: 2.0 – 8.0L



Exducer: 98mm
Inducer: 79mm
Trim: 65
Material: Forged Billet Aluminum Alloy
A/R: 0.85
Max Flow: 132 lb/min
Max Recommended Speed: 114000 RPM

Compressor Housing Connections

Inlet: 4.0″ Hose Coupler
Outlet: 107mm V-band


Exducer: 75mm
Inducer: 82mm
Trim: 84
Material: Mar-M
A/R: Supercore
Max Temp: 1050C / 1922F
Wastegate: No
Divided: Yes
