Garrett G25 660 A/R 0,92 (Reverse Rotation)


Saadaval järeltellimisel

Garrett G25-660 turbo for 1.4 – 3.0L engine displacement up to 660 horsepower. Read our guide and get more power and durability by choosing the right G25 turbo.

Horsepower: 350 – 660HP
Displacement: 1.4 – 3.0L



Exducer: 67mm
Inducer: 54mm
Trim: 65
Material: Forged Billet Aluminum Alloy
A/R: 0.70
Max Flow: 61 lb/min
Max Recommended Speed: 165000 RPM

Compressor Housing Connections

Inlet: 3.0″ Hose Coupler
Outlet: 2.0″ Hose Coupler


Exducer: 49mm
Inducer: 54mm
Trim: 84
Material: Mar-M
A/R: 0.92
Max Temp: 1050C / 1922F
Wastegate: No
Divided: No

Turbine Housing Connections

Inlet: 3.0″ V-band
Outlet: 3.5″ V-band


Garret advancing motion
